Spiral freezer

home > Product > Individual quick freezing refrigeration unit > Spiral freezer

INTRODUCTION

Dongyang's spiral belt freezer provides outstanding freezing performance for a large amount of products such as livestock, fishery and poultry products, and ice cream products. Refrigerators optimized for the spiral belt freezer guarantee the best product quality.

FEATURES

• Continuous freezing production system
• Can be installed in narrow spaces
• High productivity and efficiency
• Fast freezing speed
• Easy to handle products (frozen products)
• Hygienic thanks to easy maintenance

SPECIFICATIONS

Detail ＼ Model		DYSB250	DYSB350	DYSB500	DYSB800	DYSB1000
Capacity (kg/hr)		250	350	500	800	1000
Size (mm)	Height Width Length	2800 3500 6000	2800 4200 6700	2800 4500 7000	3400 4800 7000	3400 5400 7400
Belt type		Mesh covered omni grid
Belt width (mm)		356	457	508	508	559
Active belt width		305	356	457	457	508
Stations (tier)		9.5	8.5	8.5	13.5	14.5
Voltage		220V, 50/60Hz, 3Ph or 380V, 50/60Hz, 9Ph
Motor belt (kW)		2.2kW	2.2kW	2.2kW	2.2kW	2.2kW
Compressor motor (kW)		37kW	55kW	75kW	55kWx2	75kWx2
Air cooling unit		Aluminum plate fin & coil
Insulation panel		Polyurethane and stainless steel plates are used for the internal and external casing, respectively
Belt washer		Option

* The above specifications may be changed without prior notice for product development and quality improvement purposes.
